Motorized Pallet Flat Decoiler for Thin Steel Coil High Speed Pressing Line

group name: Flat Decoiler

Min Order: 1 piece

brand name: FANTY -Steel Coil Handling Equipment Manufacturer

model: FU Series

Nearest port for product export: shekou, shenzhen

Delivery clauses under the trade mode: FOB, CIF, EXW

Acceptable payment methods: T/T

update time: Thu, 21 Nov 2024 17:02:38 GMT

contact supplier

Paramtents

Catagory Decoiler Machine
Brand FANTY
Model FU series
Machine Color Standard white (other colors are available)
FOB Port Shenzhen
Application Electrical metal parts/Button/Eyelet stamping

Packging & Delivery

Min Order1 piece

Briefing

This Pallet Decoiler machine also called Horizontal Decoiler can handle 1500kgs of steel coils.

Detailed

As one of decoiler machine, this type motorized pallet flat decoiler, also called Horizontal Decoiler or Pallet Decoiler, specifically designed for thin steel coil high speed press line. This type pallet decoiler can load 1500kgs steel coil for its unwinding.

Whether you're producing automotive parts, household appliance components, or other metal products, our pallet decoiler caters to your diverse needs. It accommodates various coil materials, including steel and aluminum, providing flexible production options.

High-Speed Press Line 1500kgs Steel Coil Loading Flat Decoiler for Sale

Material Application
Material thickness:	0.1mm~1.0mm
Steel strip width:	0.1mm~150mm
Coil loading weight:	1500kgs
Material Type:	Steel, Aluminum, Cooper etc
Coil line Type:	High speed

Features of Flat Decoiler

* Loading weight: 1500kgs steel coil.

* High efficiency: handle a 0.1mm~1.0mm thickness steel coil.

* Accurate feeding: 24m/min feeding speed.

* Handling steel width: 150mm width steel coil handling.

* Max Loading height: 600mm steel coil loading height.

Application of Flat Decoiler

Flat feeder woking with a high speed press and it is the stamping product

Clips

Terminals

Metal button

Eyelets

Specification of Flat Decoiler

Model	FU-500	FU-1000	FU-2000
Max Steel Width(mm)	150
Coil Thickness (mm)	0.1~1.0
Loading Weight(kg)	500	800	1500
Max. Loading Height (mm)	600
Max. Coil O.D.	800	1000	1200
Feeding Speed	24m/min
Motor (HP)	0.5	1.0	2.0
Inverter	Mitsubishi	Mitsubishi	Mitsubishi
